Oldham iTrans User Manual

Hardware Overview iTrans Fixed Point Single/Dual Gas Monitor
2-4 iTrans User Manual (P/N: 77023554-1)
Figure 2-3. Locations of Input Keys and Reed Switches
Programming the gas monitor in both intrusive and non-intrusive modes
is explained in detail in Chapter 5: Operation.
2.5. Electronics Modules
The electronics module of the gas monitor contains connectors and
jumpers for wiring and configuring the device. The electronics module for a main
unit is shown in Figure 2-4. The electronics module for a remote unit is
shown in Figure 2-5. Wiring details are explained in Chapter 4: System Wiring.
