Olivetti d-Copia 2000 Service Manual

2HA/2HB
1-5-20
5. Remove the four pins holding the scanner
unit and then the unit.
Figure 1-5-43
6. Remove the screw holding the exit cover
and then the cover. Remove the two screws
holding the inner rear cover and then the
cover.
Figure 1-5-44
7. Remove the front and rear left cover.
Figure 1-5-45
Scanner unit
Pin
Pin
Pin
Pin
Inner rear cover
Exit cover
Front left cover
Rear left
cover
