Field Service Ver. 1.0 Jun. 2008 2. Other
MB-502
Maintenance
7. Remove four screws [1].
8. Loosen the screw [1], and remove
the manual bypass tray unit [2].
NOTE
• When installing the multi bypass
unit, fit the position of dowel shown
in the left illustration.
A0EPF2C013DA
[1]
[1]
A0EPF2C014DA
[1]
[2]
A0EPF2C015DA
Y109730-6 Service Manual 9
