7. Jam display Field Service Ver. 1.0 Jun. 2008
MB-502
Troubleshooting
7.2 Sensor layout
[1] Sensor in front of tim. roller (PS1)
A0EPF4C501DA
[1]
22 Service Manual Y109730-6
