Olympus DP21 - Page 13

9
SAL System
Control Box
Front view
Pilot LED
Rear view
Camera Cable
Camera head
Main switch
USB ports
DC IN connector
Display connector
DVI-I/-D/-A
RS232C connector
For connection of the
control box (U-CBS, etc.)
LAN cable connector
Camera cable connector
USB ports
Stabilizer
With 2 clamp screws
Control box
1394b connector (9-pin)
Stabilizer for Vertical
Installation
