Item Specifications
Recording media USB memories, networked PC
Image display speed
(Frame rate)
Live image: 15 fps (Displayed pixels 1600 x 1200),
27 fps (Displayed pixels 800 x 600)
Display magnifications: 1x, 2x (electronic zoom), 4x (electronic zoom)
Played image magnification: Index display, 1x, 2x, 4x
Input/output connectors DC input: Main power supply
Camera: IEEE 1394b
Interface: USB2.0
Monitor output: DVI-I Digital/Analog RGB)
Wired LAN: 100Base-TX/10Base-T
Serial ports: RS-232C, D-SUB 9-pin
Scale display View scale/Hide scale
Available microscope total magnification: 00.01x to 9999.99x
}Up to 8 total magnifications can be set
Measurement functions Distance of 2 Points, , Poly-Line, 3 Points Circle, Distance between 2 Circle Centers,
3 Points Angle, 4 Points Angle, Perpendiculars, Polygon Area, Boundary Length,
Distance of Parallel Lines, XY Distance, Count, Cross Line
}The following conditions are required to enable the measurement functions.
· Scale display: ON
· Scale setting: Entry of objective power
· Image file format: TIFF (Applicable to still image measurement in PLAY mode)
Power consumption
(Control Box)
Max. consumption: 24.2 W
During shutdown: 0 W (Apparent power: Approx. 2.0 VA)
Standby mode: 1.4 W or less
Item Specifications
PC connection configuration
System C-mount CCD camera unit
Image display speed
(Frame rate)
Live image: 7.5 fps (Displayed pixels 1600 x 1200),
27 fps (Displayed pixels 800 x 600)
Input/output connectors DC input: Main power supply
Camera: IEEE 1394b
Image sizes,
File formats
Dependent on compatible application
Applicable OS Windows Vista Ultimate 32-bit SP2, Windows Vista Business 32-bit SP2,
Windows XP Professional (SP3 or after)
Power consumption
(Camera head)
Max. consumption: 2.6 W
When the camera head is switched OFF: 0.1 W or less
