Olympus DP21 - Connection

62
Connection of U-CBM
RS232C connector
OUT 1 to 4 connectors*
(U-D7REA)
U-CBM
AC adapter for
U-CBM
RS232C cable
DP21-CB
RS232C connector
*The OUT 1 to 4 connectors are universal type connectors. The U-D7REA can be connected to any of them.
Connection of BX3-CBH
BX3-CBH
RS232C connector
RS232C cable
DP21-CB
RS232C connector
