2-3 Nomenclature
Camera Head
Any equipment connected to the camera head should be an Olympus-designated product or a product in
compliance with the requirements of IEC60950 or CISPR22/24. If equipment other than these products is
connected, Olympus cannot guarantee any performance of the camera.
Main switch
2-3-1 Hardware controls
Pilot LED
Camera cable connector
C-mount thread
AE LOCK button
(PROTECT button)
SPOT button
EXPOSE button
SHIFT button
USB port
Cursor buttons
ACCESS LED
STANDBY LED
Standby switch
OTWB button
(ERASE button)
MODE button
MENU button
SET/OK button
Hand Switch
