4 EN
Basic guide
1
Remove the body cap from the camera and the rear cap from the lens.
2
Attaching a lens to the camera.
•
Align the lens attachment mark (red) on the
camera with the alignment mark (red) on the
lens, then insert the lens into the camera’s
body (
1
). Rotate the lens in the direction
indicated by the arrow until you hear it click
(
2
).
•
Do not press the lens release button.
3
Remove the lens cap.
Removing the lens from the camera
While pressing the lens release button (
1
), rotate the lens in the
direction as indicated by (
2
).
Attaching a lens to the camera
1
2
1
2
Rear cap
Body cap
1
2
Lens cap
Alignment mark (Red)
Lens attachment mark (Red)
2
1
Lens release button
To Next Page
