Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Inverter output (U, V, W)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-
AB001-ECT
- 0.1 2.0 2.0 2.0 1.0 - - - -
- 3G3M1-
AB001-ECT
0.2 - - - - 2.0 2.0 2.0 1.2
3G3M1-
AB002-ECT
- 2.0 2.0 2.0 1.6 - - - -
- 3G3M1-
AB002-ECT
0.4 - - - - 2.0 2.0 2.0 1.9
3G3M1-
AB004-ECT
- 2.0 2.0 2.0 3.0 - - - -
- 3G3M1-
AB004-ECT
0.55 - - - - 2.0 2.0 2.0 3.5
3G3M1-
AB007-ECT
- 0.75 2.0 2.0 2.0 5.0 - - - -
- 3G3M1-
AB007-ECT
1.1 - - - - 2.0 2.0 2.0 6.0
3G3M1-
AB015-ECT
- 1.5 2.0 2.0 2.0 8.0 - - - -
- 3G3M1-
AB015-ECT
2.2 - - - - 2.0 2.0 2.0 9.6
3G3M1-
AB022-ECT
- 2.0 2.0 2.0 11.0 - - - -
- 3G3M1-
AB022-ECT
3 - - - - 2.0 2.0 2.0 12.0
3G3M1-
AB037-ECT
- 3.7 2.0 2.0 2.0 17.5 - - - -
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size
[mm2]
DC reactor connection (P1,
P(+))
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C
3G3M1-AB001-ECT - 0.1 2.0 2.0 2.0 1.3
- 3G3M1-AB001-ECT 0.2 2.0 2.0 2.0 2.7
3G3M1-AB002-ECT - 2.0 2.0 2.0 2.4
- 3G3M1-AB002-ECT 0.4 2.0 2.0 2.0 4.5
3G3M1-AB004-ECT - 2.0 2.0 2.0 4.3
- 3G3M1-AB004-ECT 0.55 2.0 2.0 2.0 5.6
3G3M1-AB007-ECT - 0.75 2.0 2.0 2.0 7.8
2 Design
2-46
M1 Series EtherCAT Type User’s Manual (I670)
