Parameter No. Item Range Display item
3003Hex-3FHex
Fin Temperature Monitor
(Real-time value)
20.0 to 125.0 [°C]
The current temperature of the cooling
fin inside the inverter is displayed. Al-
though the display is in increments of
0.1°C, the data changes in increments
of 1°C.
Display unit: °C
3003Hex-4DHex
Service Life of Main Circuit
Capacitor Elapsed T
ime
0 to 6553 [10h]
The time during which voltage is ap-
plied to the electrolytic capacitor of the
main circuit is displayed as the cumula-
tive elapsed time. The capacity of the
electrolytic capacitor of the main circuit
is measured when the main power sup-
ply is OFF, and the elapsed time is cor-
rected.
Measurement range: 0 to 65530 hours
If 65530 hours is exceeded, the accu-
mulation operation stops.
3003Hex-4EHex
Service Life of Main Circuit
Capacitor Remaining Time
0 to 6553 [10h]
The time remaining until the service life
of the electrolytic capacitor of the main
circuit is displayed.
3012Hex-2AHex
2nd Cumulative Run T
ime
of motor
0 to 9999 [x10h]
The cumulative time of the 2nd motor
run time is displayed.
3003Hex-52Hex
1st Remaining Time before
the Next Motor Mainte-
nance
0 to 9999 [x10h]
The time until the next maintenance is
displayed.
The value obtained by subtracting the
cumulative motor run time from 1st Mo-
tor Maintenance Interval
(3008Hex-4FHex) is displayed. (This
function is available only for the 1st mo-
tor)
Display: 0 to 99990
3012Hex-2DHex 2nd Number of Startups 0 to 65530
The number of operations of the 2nd
motor (number of times the RUN com-
mand for the inverter is turned ON) is
accumulated.
3003Hex-56Hex
1st Remaining Startup
T
imes before the Next Mo-
tor Maintenance
0 to 65530
The number of startups until the next
maintenance is displayed.
The value obtained by subtracting the
number of startups from 1st Preset
Startup Count for Motor Maintenance
(3008Hex-50Hex) is displayed. (This
function is available only for the 1st mo-
tor)
8 Other Functions
8-14
M1 Series EtherCAT Type User’s Manual (I670)
