Parameter No. Function name Data Default data Unit
3051Hex-10Hex/
3051Hex-13Hex/
3051Hex-16Hex
Logical Expression 1 Opera-
tion Target 1/
Logical Expression 2 Opera-
tion T
arget 1/
Logical Expression 3 Opera-
tion Target 1
0 to 241: Same as the options
for 3005Hex-15Hex
(Except 206 to 208: LOG1 to
LOG3)
0 -
3051Hex-11Hex/
3051Hex-14Hex/
3051Hex-17Hex
Logical Expression 1 Opera-
tion Target 2/
Logical Expression 2 Opera-
tion T
arget 2/
Logical Expression 3 Opera-
tion Target 2
0 -
3051Hex-12Hex/
3051Hex-15Hex/
3051Hex-18Hex
Logical Expression 1 Logical
Operator/
Logical Expression 2 Logical
Operator/
Logical Expression 3 Logical
Operator
0: AND
1: OR
2: XOR
0 -
3005Hex-15Hex/
3005Hex-1CHex
Output Terminal [DO1] Func-
tion Selection/
Output Terminal [ROA, ROB]
Function Selection
206: LOG1 (Logic operation
output 1)
207: LOG2 (Logic operation
output 2)
208: LOG3 (Logic operation
output 3)
--- -
Each logic operation output signal requires different parameter settings.
Set the necessary parameters according to the table below.
Selected signal
Logic output sig-
nal selection 1
Logic output sig-
nal selection 2
Operator selection
206: Logic operation output 1 (LOG1) 3051Hex-10Hex 3051Hex-11Hex 3051Hex-12Hex
207: Logic operation output 2 (LOG2) 3051Hex-13Hex 3051Hex-14Hex 3051Hex-15Hex
208: Logic operation output 3 (LOG3) 3051Hex-16Hex 3051Hex-17Hex 3051Hex-18Hex
(Example) To output the result of the AND operation between Run Signal (0: RUN) and Over set fre-
quency arrival signal 1 (2: FDT1) to the multifunction output terminal [DO1] as a Logic operation output
1 (LOG1).
Output T
erminal [DO1] Function Selection (3005Hex-15Hex): 206 (LOG1)
Logical Expression 1 Operation T
arget 1 (3051Hex-10Hex): 0 (RUN)
Logical Expression 1 Operation Target 2 (3051Hex-11Hex): 2 (FDT1)
Logical Expression 1 Logical Operator (3051Hex-12Hex): 0 (AND)
8 Other Functions
8-84
M1 Series EtherCAT Type User’s Manual (I670)
