Item Specifications
Con-
trol
Starting torque
• 150% min. / Rated speed of 10%
V/f control (IM motor)
V/f control (slip compensation)
V/f control with speed sensor (IM motor)
• 200% min./0.5 Hz
Vector control without speed sensor (dynamic vector control) (IM motor)
V/f control with speed feedback (Automatic torque boost)
Sensorless vector control
• 200% min./0.0 Hz (0 Hz torque control)
V
ector control with speed sensor (IM motor)
Vector control with speed and pole position sensor (PM motor)
To obtain 200% starting torque at low speed, consider raising the capacity of the
inverter to the next higher capacity.
• 200% min. / Rated speed of 10%
Vector control without speed and pole position sensor (PM motor)
To obtain these starting torques at low speed, the capacity of the inverter and
motor must be taken into consideration.
The maximum torque that can be used is limited when the current capacity match-
ed to the mode is exceeded.
Current capacity of 200% in HHD mode, 150% in HD mode, and 120% in HND and
ND modes
Protection function Overcurrent, Overvoltage, Undervoltage, Electronic thermal, Temperature error,
Ground-fault current at power-on, Inrush current protection circuit, Overload limit,
Incoming overvoltage, External trip, Memory error, CPU error, USP error, Commu-
nication error, Overvoltage suppression during deceleration, Power interruption
protection, Forced Stop, etc.
Input
sig-
nal
Frequency setting External analog input signal: Variable resistor/0 to 10 VDC
RUN/STOP com-
mand
External digital input signal (3-wire input available)
Multi-function In-
put
*3
Seven points (DI1 to DI7, Functions can be selected from among 101)
Analog input
*4
One point (voltage AI1 terminal: 10 bits/-10 to 10 VDC)
Pulse input One point (A, B, Z phases can be input, max. 32 kHz, 5 to 24 VDC)
Out-
put
sig-
nal
Multi-function out-
put
*3
One point (DO1; Functions can be selected from among 92)
Relay output
*3
One point (SPDT contact (ROA, ROB, ROC), Functions can be selected from
among 92)
Com
mu-
nica-
tions
USB USB 2.0, Micro-B connector
Other functions AVR function, V/f characteristics switching, Upper/Lower limit, Multi-step speed (16
steps), Starting frequency adjustment, Jogging operation, Carrier frequency adjust-
ment, PID control, Frequency jump, Analog gain/bias adjustment, S-shape acceler-
ation/deceleration, Electronic thermal characteristics/ level adjustment, Restart
function, T
orque boost function, Fault monitor
, Frequency conversion display, USP
function, 2nd control function, UP/DOWN, Overcurrent suppression function, etc.
1 Overview
1-15
M1 Series EtherCAT Type User’s Manual (I670)
1-3 Specifications
1
1-3-1 Standard Specifications
