Index

(hex)

Subin-

dex

(hex)

Object name Setting range Unit Default setting Size Access

PDO

map

03 FSoE Connection ID 0000 to FFFF hex --- 0000 hex 2 bytes

(U16)

RO Not pos-

sible

04 Watchdog Time 0020 to FFFD hex --- 0064 hex 2 bytes

(U16)

RO Not pos-

sible

06 Connection Type --- --- 01 hex 2 bytes

(U16)

RO Not pos-

sible

07 Communication Pa-

rameter Length

--- --- 0002 hex 2 bytes

(U16)

RO Not pos-

sible

08 Application Parame-

ter Length

--- --- 0000 hex 2 bytes

(U16)

RO Not pos-

sible

F000 --- Modular Device Profile

00 Number of Entries --- --- 02 hex 1 byte

(U8)

RO Not pos-

sible

01 Index Distance --- --- 0800 hex 2 bytes

(U16)

RO Not pos-

sible

02 Maximum Number of

Modules

--- --- 0001 hex 2 bytes

(U16)

RO Not pos-

sible

F010 --- Module List

00 Number of Entries --- --- 01 hex 1 byte

(U8)

RO Not pos-

sible

01 Subindex01 --- --- 00000316 hex 4 bytes

(U32)

RO Not pos-

sible

F050 --- Module Ident List

00 Number of Entries --- --- 01 hex 1 byte

(U8)

RO Not pos-

sible

01 Module Ident --- --- 00002000 hex 2 bytes

(U16)

RO Not pos-

sible

F980 00 Device Safety Ad-

dress

--- --- 01 hex 1 byte

(U8)

RO Not pos-

sible

01 FSoE Address 0000 to FFFF hex --- 0000 hex 2 bytes

(U16)

RO Not pos-

sible

Appendices

A-46

M1 Series EtherCAT Type User’s Manual (I670)
