Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
57 M86 Latest Light
Alarm Factor
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: No alarm
17: OH1 Heat sink overheat
18: OH2 External alarm input
19: OH3 Inverter internal overheat
22: dbH Braking resistor overheat
23: OL1 Motor 1 overload
24: OL2 Motor 2 overload
34: Reserved
35: Reserved
47: ErE Following error (excessive
speed deviation)
53: ErP RS-485 communications er-
ror (Option card)
56: Ero Position control error
58: CoF PID feedback disconnection
detected
100: FAL Detect DC fan lock
101: OL Motor overload early warn-
ing
102: OH Heat sink overheat early
warning
103: LiF Lifetime alarm
104: rEF Reference loss
105: Pid PID alarm
106: UTL Low output torque detec-
tion
107: PTC PTC thermistor activated
108: rTE Inverter life (Cumulative run
time)
109: CnT (Inverter life, Number of
startups)
0 --- --- Possible
(TxPDO)
58 M87 Light Alarm Fac-
tor Last
59 M88 Light Alarm Fac-
tor 2nd Last
5A M89 Light Alarm Fac-
tor 3rd Last
60 M95 Cumulative Run-
ning T
ime at T
rip-
ping
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 655,350
0 --- h Possible
(TxPDO)
Appendices
A-61
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-1 M Group Parameter List (Monitor 1)
To Next Page
