Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
15 W20 Transport Time
for Specified
Length
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
999.9 --- min Possible
(TxPDO)
16 W21 Power Consump-
tion Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 9,999
0 --- kW Possible
(TxPDO)
17 W22 Motor Output
Power Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 9,999
0 --- kW Possible
(TxPDO)
18 W23 Load Rate Moni-
tor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999 to 999
0 --- % Possible
(TxPDO)
19 W24 Torque Current
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999 to 999
0 --- % Possible
(TxPDO)
1A W25 Output Current
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 3,276.7
0 --- A Possible
(TxPDO)
1B W26 Magnetic Flux
Command Value
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999 to 999
0 --- % Possible
(TxPDO)
1C W27 Timed Operation
Remaining T
ime
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- s Possible
(TxPDO)
1D W28 RUN Command
Source Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
1: Terminal command (FW or RV)
22: EtherCAT
23: Support T
ool
Others: Reserved
0 --- --- Possible
(TxPDO)
Appendices
A-66
M1 Series EtherCAT Type User’s Manual (I670)
