Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
39 W56 Pulse Input (Z
Phase [PIZ])
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 16,000
0 --- p/s Possible
(TxPDO)
44 W67 Cumulative Run
Time of Capaci-
tors on Printed
Circuit Boards
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- 10 h Possible
(TxPDO)
45 W68 Cumulative Run
Time of Cooling
Fan
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- 10 h Possible
(TxPDO)
47 W70 Total Power ON
Time Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 655,350
0 --- h Possible
(TxPDO)
48 W71 Reserved Do not use. --- --- --- ---
49 W72 Internal Air High-
est Temperature
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-32,768 to 32,767
0 --- °C Possible
(TxPDO)
4A W73 Heat Sink Maxi-
mum T
empera-
ture
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-32,768 to 32,767
0 --- °C Possible
(TxPDO)
4B W74 Maximum Effec-
tive Current Val-
ue
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
0 --- A Possible
(TxPDO)
4C W75 Main Circuit Ca-
pacitor’
s Capaci-
tor Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 100.0
0 --- % Possible
(TxPDO)
4D W76 Cumulative Run
Time of Electro-
lytic Capacitors
on PC Board
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 65,535
0 --- h Possible
(TxPDO)
4E W77 Cumulative Run
T
ime of Cooling
Fan
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 65,535
0 --- h Possible
(TxPDO)
4F W78 Number of Start-
ups
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 65,535
0 --- --- Possible
(TxPDO)
50 W79 Cumulative Op-
eration Time of
Motor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 65,535
0 --- h Possible
(TxPDO)
Appendices
A-70
M1 Series EtherCAT Type User’s Manual (I670)
