Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
1D X28 Latest Alarm In-
fo. Main Circuit
DC Voltage
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 1,000.0
0.0 --- V Possible
(TxPDO)
1E X29 Latest Alarm In-
fo. Internal Air
Temperature
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-32,768 to 32,767
0 --- °C Possible
(TxPDO)
1F X30 Latest Alarm In-
fo. Heat Sink
Temperature
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-32,768 to 32,767
0 --- °C Possible
(TxPDO)
20 X31 Latest Alarm In-
fo. Input T
erminal
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0000 to FFFF hex
Bit 15: ---
Bit 14: ---
Bit 13: ---
Bit 12: EN2
Bit 11: EN1
Bit 10: ---
Bit 9: ---
Bit 8: ---
Bit 7: ---
Bit 6: DI5
Bit 5: DI4
Bit 4: DI3
Bit 3: DI2
Bit 2: DI1
Bit 1: DI7
Bit 0: DI6
0
--- --- Possible
(TxPDO)
Appendices
A-94
M1 Series EtherCAT Type User’s Manual (I670)
