Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
06 E05 Input Terminal
[DI5] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 188 (normally-open input)
1,000 to 1,188 (normally-close input)
Refer to 8-2-1 Multifunction Input Se-
lection on page 8-23.
8 --- --- Possible
0B E10 2nd Acceleration
Time 1
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 6,000.00
6.00
√
s Possible
0C E11 2nd Deceleration
Time 1
0D
E12 1st Acceleration
Time 2
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 6,000.00
6.00
√
s Possible
0E E13 1st Deceleration
T
ime 2
0F
E14 2nd Acceleration
Time 2
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 6,000.00
6.00
√
s Possible
10 E15 2nd Deceleration
T
ime 2
1
1 E16 Torque Limit 3
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 300
300
√
% Possible
12 E17 Torque Limit 4
15 E20 Output Terminal
[DO1] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 241 (normally-open output)
1,000 to 1,241 (normally-close out-
put)
Refer to 8-2-2 Multifunction Output
Selection on page 8-28
.
0
--- --- Possible
1C E27 Output Terminal
[ROA, ROB]
Function Selec-
tion
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 241 (normally-open output)
1,000 to 1,241 (normally-close out-
put)
Refer to 8-2-2 Multifunction Output
Selection on page 8-28.
99
--- --- Possible
1E E29 Frequency Arriv-
al 2 ON Timer
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.01 to 10.00
0.1
√
s Possible
Appendices
A-115
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-6 E Group Parameter List (Terminal Functions)
To Next Page
