Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
2F E146 2nd Overload
Protect Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: Enable at constant speed
2: Enable during ACC/constant
speed operation (Disable during
DEC)
2
√
--- Possible
30 E147 2nd Overload
Protect Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
20 to 200
180
√
% Possible
35 E152 Starting Frequen-
cy Selection at
Frequency Pull-in
Restart
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Frequency at which the power fail-
ure occurred
1: Maximum output frequency
2: Frequency command
3: Starting frequency
3 --- --- Possible
37 E154 RUN Time Over
(RNT)/Power ON
Time Over (ONT)
Detection Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- 10 h Possible
3A E157 Analog Input
[AI1] Detection
Upper Limit Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 100
100
√
% Possible
3B E158 Analog Input
[AI1] Detection
Lower Limit Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 100
0
√
% Possible
3C E159 Analog Input
[AI1] Level De-
tection Hystere-
sis Width
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 10
0
√
% Possible
40 E163 Analog Operation
Level at [AI1]
Disconnection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-100 to 100
999: Disable
*1
999 --- % Possible
42 E165 Carrier Frequen-
cy Automatic Re-
duction Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: Enable
1 --- --- Possible
Appendices
A-122
M1 Series EtherCAT Type User’s Manual (I670)
