Index

(hex)

Sub-

index

(hex)

Pa-

rame-

ter No.

Function name Monitor or data range

Default

data

Set-

ting

dur-

ing

RUN

Unit

PDO

map

06 C05 Multi-step Speed

Reference 1

V/f DTV

PG V/f PG DTV

SLV PGV

PM SLV PM PGV

0.00 to 590.00

0.00

√

Hz Possible

07 C06 Multi-step Speed

Reference 2

08 C07 Multi-step Speed

Reference 3

09 C08 Multi-step Speed

Reference 4

0A C09 Multi-step Speed

Reference 5

0B C10 Multi-step Speed

Reference 6

0C C11 Multi-step Speed

Reference 7

0D C12 Multi-step Speed

Reference 8

0E C13 Multi-step Speed

Reference 9

0F C14 Multi-step Speed

Reference 10

10 C15 Multi-step Speed

Reference 1

1 C16 Multi-step Speed

Reference 12

12 C17 Multi-step Speed

Reference 13

13 C18 Multi-step Speed

Reference 14

14 C19 Multi-step Speed

Reference 15

15 C20 Jogging Fre-

quency

V/f DTV

PG V/f PG DTV

SLV PGV

PM SLV PM PGV

0.00 to 590.00

0.00

√

Hz Possible

16 C21 Pattern Opera-

tion Function Se-

lection

V/f DTV

PG V/f PG DTV

SLV PGV

PM SLV PM PGV

0: 1 cycle operation (Pattern opera-

tion)

1: Repetition operation (Pattern oper-

ation)

2: Constant speed operation (Pattern

operation) after 1 cycle operation

0 --- --- Possible

Appendices

A-126

M1 Series EtherCAT Type User’s Manual (I670)
