Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
17 C22 Pattern Opera-
tion Stage 1 Op-
eration Setting
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0000 to FFFF hex
Bit 15: 0 = Forward, 1 = Reverse
Bit 14: Fixed to 0 (Not used)
Bit 13 to 12: Acceleration/Decelera-
tion time selection
0: 1st Acceleration Time 1 (F07)
/1st Deceleration Time 1 (F08)
1: 2nd Acceleration Time 1 (E10)
/2nd Deceleration Time 1 (E11)
2: 1st Acceleration Time 2 (E12)
/1st Deceleration Time 2 (E13)
3: 2nd Acceleration Time 2 (E14)
/2nd Deceleration Time 2 (E15)
Bit 11 to 10: Minimum unit of opera-
tion time
0 = X0.01
1 = X0.1
2 = X1
3 = X10
Bit 9 to 0: Data part of operation time
• If Minimum unit is 0: X0.01,
000 to 3E7 hex (0.00 to 9.99)
• If Minimum unit is 1: X0.1,
064 to 3E7 hex (10.0 to 99.9)
*1
• If Minimum unit is 2: X1,
064 to 3E7 hex (100 to 999)
*1
• If Minimum unit is 3: X10,
064 to 258 hex (1,000 to 6,000)
*2
*1. 0000 to 0063 hex and 03E8 to 03FF
hex cannot be set.
*2. 0000 to 0063 hex and 0259 to 03FF
hex cannot be set.
0
√
--- Possible
18 C23 Pattern Opera-
tion Stage 2 Op-
eration Setting
19 C24 Pattern Opera-
tion Stage 3 Op-
eration Setting
1A C25 Pattern Opera-
tion Stage 4 Op-
eration Setting
1B C26 Pattern Opera-
tion Stage 5 Op-
eration Setting
1C C27 Pattern Opera-
tion Stage 6 Op-
eration Setting
1D C28 Pattern Opera-
tion Stage 7 Op-
eration Setting
1F C30 2nd Frequency
Reference Selec-
tion
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
1: Analog voltage input (terminal
[AI1])
7: UP/DOWN control
10: Pattern operation
12: Pulse train input
13: Calculation result
15: EtherCAT
15
--- --- Possible
Appendices
A-127
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-7 C Group Parameter List (Frequency Reference and Analog Input Functions)
