Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
20 C31 Input Terminal
[AI1] Offset
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-5.0 to 5.0
0.0
√
% Possible
21 C32 Input Terminal
[AI1] Gain (Com-
mand)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 400.00
100.00
√
% Possible
22 C33 Input Terminal
[AI1] Filter
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 5.00
0.05
√
s Possible
23 C34 Input Terminal
[AI1] Gain (Ana-
log Input)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 100.00
100.00
√
% Possible
24 C35 Input Terminal
[AI1] Polarity Se-
lection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Bipolar
1: Unipolar
1 --- --- Possible
33 C50 Input Terminal
[AI1, AI2] Bias
Analog Input for
1st Frequency
Command
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 100.00
0.00
√
% Possible
36 C53 Input Terminal
[AI1, AI2] Nor-
mal/Inverse Op-
eration for 1st
Frequency Com-
mand
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Normal
1: Inverse
0
√
--- Possible
37 C54 Input Terminal
[AI1, AI2] Nor-
mal/Inverse Op-
eration for 2nd
Frequency Com-
mand
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Normal
1: Inverse
0
√
--- Possible
38 C55 Input Terminal
[AI1] Bias (Com-
mand)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-200.00 to 200.00
0.00
√
% Possible
39 C56 Input Terminal
[AI1] Bias (Ana-
log Input)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 100.00
0.00
√
% Possible
3B C58 Reserved Do not use. --- --- --- ---
Appendices
A-128
M1 Series EtherCAT Type User’s Manual (I670)
