Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
1B H26 Thermistor Func-
tion Selection
(MOH)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: PTC (Inverter immediately trips
with OH4 displayed)
2: PTC (Inverter issues output signal
MOH and continues to run)
0
√
--- Possible
1C H27 1st Thermistor
Error Detection
Level (MOH)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 5.00
1.60
√
V Possible
1D H28 Droop Control
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-60.0 to 0.0
0
√
Hz Possible
2B H42 Main Circuit Ca-
pacitor Service
Life Coef
ficient
(Measurement
V
alue)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Start measurement
1: Measurement failure
2 to 65,535: Measurement value
For replacement timing adjustment
(For monitoring)
0
√
--- Possible
2C H43 Cumulative run
time of cooling
fan
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
For replacement timing adjustment
(For monitoring)
0
√
10 h Possible
2D H44 1st Startup Count
for Motor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 65,535
Cleared to 0 by the writing of 0
0
√
--- Possible
2E H45 Mock Alarm
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable
1: Enable (Generate mock alarm)
0
√
--- Possible
2F H46 Auto Search De-
lay Time 2 for
Starting Mode
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.1 to 100.0
1.0
√
s Possible
Appendices
A-135
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-9 H Group Parameter List (High Level Functions)
