Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
19 H324 Input Terminal
[DI1] Response
Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
1 to 400
1 --- ms Possible
1A H325 Input Terminal
[DI2] Response
T
ime
1B
H326 Input Terminal
[DI3] Response
Time
1C
H327 Input Terminal
[DI4] Response
Time
1D
H328 Input Terminal
[DI5] Response
Time
1E
H329 Input Terminal
[DI6] Response
Time
1F
H330 Input Terminal
[DI7] Response
Time
21
H332 Torque Refer-
ence Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Analog input
2: Parameter (Torque Reference)
(H333)
5: EtherCA
T
0 --- --- Possible
22 H333 Torque Refer-
ence
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 200
0
√
% Possible
23 H334 Torque Bias Po-
larity Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: As signed
1: Depend on run direction
0 --- --- Possible
3052 0C H411 Input Phase Loss
Protection Func-
tion Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable (Continue to run)
1: Enable (Trip)
1
√
--- Possible
0D H412 Output Phase
Loss Protection
Function Selec-
tion
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Disable (Continue to run)
1: Enable (Trip)
0
√
---
Possible
Appendices
A-144
M1 Series EtherCAT Type User’s Manual (I670)
