Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
12 H317 Logical Expres-
sion 1 Logical
Operator
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: AND
1: OR
2: XOR
0 --- --- Possible
13 H318 Logical Expres-
sion 2 Operation
Target 1
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 241 (normally-open output)
1,000 to 1,241 (normally-close out-
put)
Refer to 8-2-2 Multifunction Output
Selection on page 8-28.
27, 100, 206, 207, and 208 cannot
be selected.
0
--- --- Possible
14 H319 Logical Expres-
sion 2 Operation
T
arget 2
15
H320 Logical Expres-
sion 2 Logical
Operator
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: AND
1: OR
2: XOR
0 --- --- Possible
16 H321 Logical Expres-
sion 3 Operation
T
arget 1
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 241 (normally-open output)
1,000 to 1,241 (normally-close out-
put)
Refer to 8-2-2 Multifunction Output
Selection on page 8-28.
27, 100, 206, 207, and 208 cannot
be selected.
0
--- --- Possible
17 H322 Logical Expres-
sion 3 Operation
T
arget 2
18
H323 Logical Expres-
sion 3 Logical
Operator
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: AND
1: OR
2: XOR
0 --- --- Possible
Appendices
A-143
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-9 H Group Parameter List (High Level Functions)
To Next Page
