Page #726 background imageLoading...
Page #726 background image
Value Mantissa part Exponent part 10 to the power of (exponent part - 2)
1,000 to 9,999 1,000 to 9,999 2 1
10,000 to 99,990 1,000 to 9,999 3 10
Example: Rotate Speed Monitor (3010-09 hex) = 99,990 r/min
99,990 = Mantissa part: 9,999 (270F hex), Exponent part: 3 = E70F hex →
E7Hex 0
FHex
Example: Rotate Speed Monitor (3010-09 hex) = 9,999 r/min
9,999 = Mantissa part: 9,999 (270F hex), Exponent part: 2 = A70F hex →
A7Hex 0
FHex
Example: Rotate Speed Monitor (3010-09 hex) = 9.999 r/min
999.9 = Mantissa part: 9,999 (270F hex), Exponent part: 1 = 670F hex →
67Hex 0
FHex
Example: Rotate Speed Monitor (3010-09 hex) = 99.99 r/min
99.99 = Mantissa part: 9,999 (270F hex), Exponent part: 0 = 270F hex →
27Hex 0
FHex
Data Format [41]: Alarm History
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Number of consecutive occurrences
of the same alarm
Alarm code*1
*1
: For alarm codes, refer to “Data Format [10]: Alarm Code” in this section.
This gives the contents of the alarm that occurred and the number of consecutive occurrences of the
alarm.
Example: Last Alarm History/Number of Consecutive Same Alarms (301
1-06 hex) = 021B hex
02Hex 1
BHex
→ Number of consecutive occurrences of the same alarm: 2, Alarm code: 1B hex = 27
OS (Overspeed)
Data Format [43]: Operation Command (for I/O Check)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
00
Not used General-purpose input
EN1EN2
DI5 DI4 DI3 DI2 DI1 DI7 DI60 000 0
EN input Not used
(All bits are ON with 1.)
Example: Input Terminal Monitor
(3010-29 hex) = 0061 hex
00Hex 6
1Hex
→ 0000 0000 0110 0001
b
= DI4, DI5, and DI6 are ON
Data Format [44]: Operation Status 2
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Not
used
Operation status
OL2OL LOC REF THM IPF
SETM
IRDY FDT1 FAR1OLP LIFE OHF TRY FAN0
Appendices
A-180
M1 Series EtherCAT Type User’s Manual (I670)
