Event name Enable Circuit Failure Event code 088A0000 hex
Meaning A circuit error was detected in the diagnosis of the enable circuit.
Source EtherCAT Master Function Mod-
ule
Source details Slave Detection tim-
ing
Continuously
Error attrib-
utes
Level Minor fault Recovery Error reset Log category System log
Effects User program Continues. Operation Motor stops.
Indicators EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System-de-
fined varia-
bles
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
(1) There is a contact failure on
the control terminal block board.
Confirm that the control terminal
block board is firmly installed on
the inverter
.
→ Cycle the power supply to re-
set the alarm.
Confirm that the control terminal
block board is firmly installed on
the inverter.
(2) Enable circuit logic error
• Confirm that the output from
safety switches or other devi-
ces is input with the same log-
ic (High/High or Low/Low) for
both
SF1 and SF2 terminals.
• Check that the two poles of
SW9 on the control board are
both ON/ON or OFF/OFF.
→ Reset the alarm by executing
Reset (Refer to
6-8-1 Reset
Function on page 6-43).
Set the output from the safety
switches, etc. so that both SF1
and SF2 terminals have the
same logic.
(3) An enable circuit (safety stop
circuit) failure (single failure) was
detected.
If the problem cannot be solved
with the above correction, the in-
verter is faulty.
None
Attached in-
formation
None
Precautions/
Remarks
None
Appendices
A-275
M1 Series EtherCAT Type User’s Manual (I670)
A-5 Sysmac Error Status Codes
A
A-5-2 Error Descriptions
