Power
supply
line
Standard applicable
motor (kW)
Inverter model Specifications Fuse rating (A)
Three-
phase 400
V
0.4 3G3M1-A4004-ECT HHD 50 (IEC 60269-4)
0.75 HND
HD
ND
3G3M1-A4007-ECT HHD 50 (IEC 60269-4)
1.1 HND
HD
1.5 ND
3G3M1-A4015-ECT HHD 50 (IEC 60269-4)
2.2 HND
HD
ND
3G3M1-A4022-ECT HHD 63 (IEC 60269-4)
3.0 HND
HD
ND
3G3M1-A4030-ECT HHD 63 (IEC 60269-4)
4.0 HND
HD
ND
3G3M1-A4040-ECT HHD 63 (IEC 60269-4)
5.5 HND
HD
ND
3G3M1-A4055-ECT HHD 100 (IEC 60269-4)
7.5 HND
HD
3G3M1-A4075-ECT HHD 100 (IEC 60269-4)
11 3G3M1-A4055-ECT ND 100 (IEC 60269-4)
3G3M1-A4075-ECT HND 100 (IEC 60269-4)
HD
3G3M1-A4110-ECT HHD 125 (IEC 60269-4)
15 3G3M1-A4075-ECT ND 100 (IEC 60269-4)
3G3M1-A4110-ECT HND 125 (IEC 60269-4)
HD
3G3M1-A4150-ECT HHD 160 (IEC 60269-4)
2 Design
2-72
M1 Series EtherCAT Type User’s Manual (I670)
