• User preference dataset saved by User Preference Dataset Registration (3020Hex-5EHex) are not
initialized. (Refer to 6-1-2 User Preference Dataset (Registration/Protection) on page 6-6.)
Initialize motor 1 parameters (3008Hex-04Hex= 2)
• When “2: Initialize motor 1 parameters” is set to Data Initialization (3008Hex-04Hex), the following
parameters are set to their default data (values at the time of shipment from the factory).
1st Manual Torque Boost V
oltage (3004Hex-0AHex)
1st Motor Electronic Thermal Level (3004Hex-0CHex)
1st Motor Pole Number (3007Hex-02Hex)
1st Motor Rated Current (3007Hex-04Hex)
1st Motor Armature Resistance (3007Hex-07Hex)
1st Motor Parameter %R1 (3007Hex-08Hex)
1st Motor Parameter %X (3007Hex-09Hex)
1st Slip Compensation Gain for Braking (3007Hex-0CHex)
1st Rated Slip Frequency (3007Hex-0DHex)
1st Iron Loss Factor 1 (3007Hex-0EHex)
1st Magnetic Saturation Factor 1 (3007Hex-11Hex)
1st Magnetic Saturation Factor 2 (3007Hex-12Hex)
1st Magnetic Saturation Factor 3 (3007Hex-13Hex)
1st Magnetic Saturation Factor 4 (3007Hex-14Hex)
1st Magnetic Saturation Factor 5 (3007Hex-15Hex)
1st PM Motor Starting Method (3007Hex-1FHex)
1st Motor Torque Current under Vector Control (3007Hex-38Hex)
1st Induced Voltage Factor under Vector Control (3007Hex-39Hex)
1st PM Motor Armature Resistance (3007Hex-3DHex)
1st PM Motor d-axis Inductance (3007Hex-3EHex)
1st PM Motor q-axis Inductance (3007Hex-3FHex)
1st PM Motor Induced Voltage Ke (3007Hex-40Hex)
1st PM Motor Iron Loss (3007Hex-41Hex)
1st PM Motor Reference Current for Magnetic Pole Detection (3007Hex-58Hex)
1st PM Motor Overcurrent Protection Level (3007Hex-5BHex)
Auto Search Delay Time 2 for Starting Mode (3008Hex-2FHex)
Magnetic Flux Level during Deceleration (3014Hex-5BHex)
Initialize Motor 2 Parameters (3008Hex-04Hex= 3)
• When “3: Initialize motor 2 parameters” is set to Data Initialization (3008Hex-04Hex), the following
parameters are set to their default data (values at the time of shipment from the factory).
2nd Manual Torque Boost V
oltage (3009Hex-06Hex)
2nd Motor Electronic Thermal Level (3009Hex-08Hex)
2nd Motor Pole Number (3009Hex-10Hex)
2nd Motor Rated Current (3009Hex-12Hex)
2nd Motor Armature Resistance (3009Hex-15Hex)
2nd Motor Motor Constant %R1 (3009Hex-16Hex)
2nd Motor Motor Constant %X (3009Hex-17Hex)
6 Basic Settings
6-4
M1 Series EtherCAT Type User’s Manual (I670)
