Parameter No. Data Description Reference item Page
3005Hex-15Hex,
3005Hex-1CHex
35 RUN2: Inverter outputting Run Signal page 6-61
36 OLP:
Overload prevention control-
ling
Overload Limit/Overload
Warning
page
8-7137
OL2: Overload warning 2
38 OL: Overload warning
41 LOC: Light load detection signal
Light load detection sig-
nal
page
8-90
42 OD: Excessive PID deviation PID function
page
8-108
43 PID-CTL: Under PID control PID function
44 PID-STP:
Under sleep mode of PID
control
PID function
46 OTQ: Overtorque Overtorque/undertorque page 7-86
48 SWM1: 1st motor in operation
1st control under selec-
tion signal
page
8-92
49 SETM: 2nd motor in operation
2nd control under selec-
tion signal
52 FWR: Forward run signal Forward run signal page 6-62
53 RVR: Reverse run signal Reverse run signal page 6-62
54 Do not set. - -
56 MOH:
Motor overheat detected by
thermistor
Thermistor Trip Function
page
8-77
57 BRK: Brake release Brake control function page 7-72
59 AIIDc:
Analog AI2 (All) disconnec-
tion detection
Window comparator
page
8-91
70 ZS: 0 Hz signal 0 Hz detection function page 6-63
71 DSAG: Speed agreement
Motor control method
with speed sensor
page 7-12
72 FAR3: Frequency arrival signal 3 Frequency arrival signal
page
8-78
76 DSE: Excessive speed deviation
Motor control method
with speed sensor
page 7-12
77 U-EDC:
Low DC link bus voltage de-
tection
Low DC link bus voltage
detection
page
8-93
79 IPF2:
During decelerating at mo-
mentary power failure
Restart after Momentary
Power Failure
page
8-48
82 POK: Position ready Position control page 7-36
84 MNT:
Maintenance timer counted
up
Maintenance monitor
page
8-82
87
FAR1FDT
1:
Frequency match detection Frequency arrival signal
page
8-78
89 PTD: Pole tuning done Synchronous motor (PM) page 7-25
90 Do not set. - -
91 Do not set. - -
92 Do not set. - -
93 Do not set. - -
95 Do not set. - -
98 L-ALM: Minor alarm Minor alarm list
page
8-95
99 AL: Alarm output Alarm list page 6-63
8 Other Functions
8-30
M1 Series EtherCAT Type User’s Manual (I670)
