Value Description
06 to 0D hex The written value can be read.
0E to FF hex An abort code is returned.
• Subindex 04 hex New Messages Available gives whether there are new messages to be read.
Value of subindex 04
hex
Description
0 No new message to be read.
1 New messages to be read are available.
• Subindex 05 hex Flags sets whether or not to notify the Diagnosis History as an emergency mes-
sage. It is set to 0000 hex (not notify) when power is turned ON. Write 0001 hex to send emergency
messages.
•
Subindexes 06 to 0D hex Diagnosis Message 1 to Diagnosis Message 8 give the Diagnosis His-
tory. Diagnosis History is saved in Diagnosis Message 1 to 8 in ascending order. When 8 messages
are saved, the 9th message is saved in Diagnosis Message 1 and the sequence starts again.
The format of the Diagnosis History is shown below.
Items of subindex 06
to 0D hex
Data type Details
Diag Code UINT32 Bit 16 to 31: Emergency Error Code (Object 603F hex)
Bit 0 to 15: E800 hex
Flags UINT16 Bit 8 to 15: 01 hex (number of parameters)
Bit 4 to 7: 02 hex (time stamp is based on time distribution)
Bit 0 to 3: Type 0: Info message
1: W
arning message
2: Alarm
T
ext ID UINT16 0000 hex: No text ID
Time Stamp UINT64 0: No time stamp
Not 0: Time information (Contents of object 10F9-01 hex at occurrence of
event)
Flags Parameter 1
UINT16 Bit 12 to 15: 1 hex
Bit 0 to 11: 00C hex (size of parameter 1)
Parameter 1 ARRA
Y (0.4) OF
BYTE
Contents of Sysmac Minor Fault (2004 hex) and Sysmac Observation (2003
hex)
The time stamp is recorded based on the contents of 10F9-01 hex at the time of occurrence of the
event.
If the time information cannot be obtained from 10F9-01 hex, the time stamp on the Sysmac Studio
will be displayed as 1970/1/1 0:00:00. The time stamp of a Diagnosis Message that is saved before
the time information is obtained from 10F9-01 hex will also be displayed as 1970/1/1 0:00:00.
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default set-
ting
Data
attrib-
ute
Size
Ac-
cess
PDO
map
Complete
access
Modes of
operation
10F9 --- Present Time for
Event Log
--- --- --- --- --- --- --- Possible ---
00 Number of en-
tries
--- --- 01 hex --- 1 byte
(U8)
RO --- --- ---
01 Present Time for
Event Log
0 to
18,446,74
4,073,709
,551,615
--- 0 A 8 bytes
(U64)
W --- --- ---
Appendices
A-14
M1 Series EtherCAT Type User’s Manual (I670)
