Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
52 W81 Integrated Power
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 999,900.0
0 --- kWh Possible
(TxPDO)
53 W82 Data Used Inte-
grating Electric
Power
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 9,999
0 --- --- Possible
(TxPDO)
57 W86 Reserved Do not use. --- --- --- ---
58 W87 Inverter ROM
Version 1 Main
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 59,999
0 --- --- Possible
(TxPDO)
59 W88 Inverter ROM
Version 2 Sub
5A
W89 ROM Version
Operator
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- --- Possible
(TxPDO)
5B W90 ROM version
(ECT terminal
board 1)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- --- Possible
(TxPDO)
5C W91 ROM Version
ECT Terminal
Board 2
60
W95 Reserved Do not use. --- --- --- ---
61 W96 Reserved Do not use. --- --- --- ---
62 W97 Contents of ECT
T
erminal Board
error
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
0 --- --- Possible
(TxPDO)
3017 0B W110 Motor Speed
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- r/min Possible
(TxPDO)
0C W111 Load Shaft
Speed
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- r/min Possible
(TxPDO)
10 W115 Output Frequen-
cy After Slip
Compensation
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
0 --- Hz Possible
(TxPDO)
11 W116 PG Feedback
Value
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
0 --- Hz Possible
(TxPDO)
Appendices
A-71
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-2 W Group Parameter List (Monitor 2)
