Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
43 E166 Non-linear V/f
Frequency 1
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
44 E167 Non-linear V/f
Voltage 1
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
45 E168 Non-linear V/f
Frequency 2
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
46 E169 Non-linear V/f
Voltage 2
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
47 E170 Non-linear V/f
Frequency 3
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
48 E171 Non-linear V/f
Voltage 3
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
49 E172 Non-linear V/f
Frequency 4
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
4A E173 Non-linear V/f
Voltage 4
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
4B E174 Non-linear V/f
Frequency 5
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
Appendices
A-123
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-6 E Group Parameter List (Terminal Functions)
