Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
4C E175 Non-linear V/f
Voltage 5
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
4D E176 Non-linear V/f
Frequency 6
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
4E E177 Non-linear V/f
Voltage 6
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
4F E178 Non-linear V/f
Frequency 7
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0: Disable
0.1 to 590.0
0.0 --- Hz Possible
50 E179 Non-linear V/f
Voltage 7
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 240 (200 V class series)
0 to 500 (400 V class series)
0 --- V Possible
52 E181 Acceleration Wait
Time on Brake
Control
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.000 to 5.000
0.000 --- s Possible
55 E184 Low Current De-
tection Condition
Selection (LOC)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Output during acceleration/decel-
eration and constant-speed opera-
tion
1: Output only during constant-speed
operation
1 --- --- Possible
56 E185 Overload Warn-
ing Detection
Condition Selec-
tion (OL1, OL2)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Output during acceleration/decel-
eration and constant-speed opera-
tion
1: Output only during constant-speed
operation
1 --- --- Possible
Appendices
A-124
M1 Series EtherCAT Type User’s Manual (I670)
