Omron 3G3M1-A4110-ECT User Manual

Item
Terminal sym-
bol
Terminal name Description Specifications
Digital Power supply DIC Input signal com-
mon
Common terminal for
the digital input.
Input Con-
tact
DI1
DI2
DI3
DI4
DI5
DI6
DI7
Multifunction in-
put terminal
Select functions and
allocate them to termi-
nals DI1 to DI7. These
terminals support both
the sink logic and the
source logic.
For details on the con-
nection, refer to Multi-
function Input T
ermi-
nals and Programma-
ble Controller Connec-
tion
on page 2-61.
Voltage between each
input terminal and the
terminal DIC
ON voltage: 20 V min.
OFF voltage: 2 V max.
Allowable voltage: 27
VDC max.
Load current (DI1,
DI2): 2.5 to 16 mA (at
27 V)
Load current (DI3 to
DI7): 2.5 to 5 mA (at
27 V)
Internal resistance:
5.4 kΩ
SF1
SF2
Safety input Turn ON the Safety
Function Selector
Switch to enable this
terminal.
SF1 (Safety input 1)
SF2 (Safety input 2)
Voltage between each
input terminal and the
terminal DIC
ON voltage: 20 V min.
OFF voltage: 2 V max.
Allowable voltage: 27
VDC max.
Load current: 2.5 to 5
mA (at 27 V)
Internal resistance:
6.6 kΩ
Pulse PIA
PIB
PIZ
Pulse input This is pulse input for
frequency setting.
This terminal accepts
5 to 24 VDC input sig-
nals.
Input pulse: 32 kHz
max.
Internal resistance:
7.2 kΩ
Voltage between input
and DIC:
5 to 24 VDC
ON voltage: 4 V min.
OFF voltage: 2 V max.
Allowable voltage: 27
VDC max.
2 Design
2-14
M1 Series EtherCAT Type User’s Manual (I670)
