2 Installation and connection
2-1 Installation
BU100RS
2-1-2 Stationary installation
Perform installation only as shown in the diagrams below.
● Horizontal installation
Attach the included rubber feet for horizontal installation and position the unit horizontally.
For stationary horizontal installation, make sure that this product does not slide or fall.
● Upright installation
Fix the brackets (2p) using M3 flat head screws (6p) provided with the product option
(model BAP100R) to the UPS with the specified torque (0.55±0.1N･m).
