9 References
9-1 Specifications
BU100RS
9 References
9-1 Specifications
Method
Full-time inverter supply method (Automatic Switching)
Input
Input voltage range
70±2 to 146±2 V AC (with less than 90% connection load)
80±2 to 146±2 V AC (with 90% or more connection load)
Frequency
Single-phase, two-wire (grounded)
Output
Voltage
Commercial
100V mode: 100VAC±2%, 110V mode: 110VAC±2%
115V mode: 115VAC±2%, 120V mode: 120VAC±2%
Backup operation
100V mode: 100VAC±2%, 110V mode: 110VAC±2%
115V mode: 115VAC±2%, 120V mode: 120VAC±2%
Frequency
Synchronous mode
Commercial operation: Synchronized with input frequency
Backup operation: 50/60 Hz±0.1 Hz
Frequency selection: Automatic selection when UPS start
Asynchronous mode
Commercial operation: 50/60 Hz±0.5%
Backup operation: 50/60 Hz±0.5%
Waveform
Distortion rate
6% max. (Rectified load, at rated output)
3% max. (Resistance load, at rated output)
Single-phase, two-wire (grounded)
Output receptacle NEMA 5-15R x 4 / Terminal block
Battery
Voltage / Capacity x Quantity
Backup time (25°C, initial characteristics)
5 min. or more (700W) / 4 min. or more (800W)
Environ-
ment
Operating environment temperature/ humidity
0 °C to 40 °C, 25 to 85%RH with no condensation
-15 °C to 40 °C, 10 to 90%RH with full charged and no condensation
Safety standard / RoHS directive compliance
Disturbance voltage /
Radiated interference field strength
VCCI Class A compliant
Internal power consumption (normal/maximum)
Dimensions (W x D x H) *4
438 mm x 378 mm x 85 mm (including the input cable cover)
*1: Minimum input voltage 70V for 100V mode with 90% load
*2: Dimensions without input cable cover: 438 x 315 x 85
Note: About ECO mode, see p. 42.
