1 Features and System Configuration

1 - 6

CJ-series EtherCAT Slave Units Operation Manual (W541)

Interface with multiple networks such as EtherCAT and DeviceNet.

Integration with Other Networks

EtherCAT Slave Unit

EtherCAT master

DeviceNet Master Unit

DeviceNet network

EtherCAT network

DeviceNet slaves

CPU Unit
