5 Troubleshooting

5 - 6

CJ-series EtherCAT Slave Units Operation Manual (W541)

The flashing patterns for flickering, blinking, single flash, and double flash are given below.

off

Flickering

Blinking

Single flash

Double flash

200 ms 200 ms

50 ms

1,000 ms

200 ms

sm 002sm 002

200 ms 200 ms
