A
A-5 Comparison between CP1L and CP1E
176 SYSMAC CP1L/CP1E Introduction Manual
Appendix
■Connection with Programming Devices
Item CP1L CPU Units CP1E E-type CPU Units CP1E N-type CPU Units
CX-Programmer
Connecting tool CX-Programmer CX-Programmer for CP1E
CX-Programmer
CX-Simulator Provided. Provided.
Utility - Switch Box
Error simulator
Programming Device
connection port
USB port
Optional serial
communication board
USB port only USB port only
Applicable Support Software CX-Programmer version 7.1
or higher
CX-Programmer for CP1E version 1.0 or higher
CX-Programmer version 8.2 or higher
Interchangeability with CXP files
of CP1L
- CX-Programmer for CP1E file extension is “CXE”.
CX-Programmer for CP1E cannot open a CXP file. But CXP
files of CP1L can be copied and then pasted into the CX-
Programmer for CP1E.
CXE files can be processed with CX-Programmer.
Program
protection
Read protection
from the CX-
Programmer
Supported.
Protection can be set by
task.
Supported.
It is the protection for the whole program.
Read protection cannot be set by task.
Enabling and
disabling
overwriting
programs from
the CX-
Programmer
Supported. Not supported.
FINS write
protection for
CPU Unit via
Network
Supported. Not supported.
Enabling and
disabling writing
program files for
file memory
Supported. Not supported.
PLC backup tool Supported. Not supported.
CPS files Supported. Not supported.
Changing the PV refreshing
format (BCD or binary) for
timers/counters
Need to set. Not need to set.
Changing timer PVs Possible. Impossible.
Changing during online editing.
Others
PT
SAP Supported. Not supported.
Ladder monitor Supported. Not supported.
PT programming
console
Supported. Not supported.
Trouble shoot Supported. Not supported.
Daikansan Supported. Not supported.
FINS Supported. Supported.
A part of FINS are not supported.
Refer to CP1E CPU Unit Software User’s Manual.
To Next Page
