54
Cables, Connectors, and Related Devices Section 2-3
Cable Wiring Direction and Connector Insertion Direction
DCN1-1C/3C
DCN1-2C/4C
DCN1-2R/4R
Wiring
direction
Insertion
direction
Wiring
direction
Insertion
direction
Insertion
direction
Wiring
direction
