Omron E5*C Series User Manual

4 Basic Operation
4 - 24
E5@C-T Digital Temperature Controllers User’s Manual (H185)
Assigned Output Functions
E5CC-T
E5EC-T or E5AC-T
* If the Controller is equipped with HB/HS alarm detection, it is set by default to detect heater alarms (HA).
Therefore, the alarm 1 function is disabled and the Alarm 1 Type is not displayed. To enable alarm 1, set an
output assignment to alarm 1.
z Alarms
It will be specified in this section when an alarm must be assigned, i.e., when an alarm must be set
for the Control Output 1 or 2 Assignment parameters, or for the Auxiliary Output 1 to 4 Assignment
parameters. For example, if alarm 1 is set for the Control Output 1 Assignment parameter, then
alarm 1 has been assigned.
Assigning a work bit to either control output 1 or 2 or to auxiliary output 1 to 4 is also considered to
be the same as assigning an alarm. For example, if work bit 1 is set for the Auxiliary Output 1
Assignment parameter, then alarms 1 to 4 have been assigned.
Parameter name Display
Without control output 2 With control output 2
Standard Heating/cooling Standard Heating/cooling
Control Output 1
Assignment
out1 Control output
(heating)
Control output
(heating)
Control output
(heating)
Control output
(heating)
Control Output 2
Assignment
out2 --- --- Not assigned. Control output
(cooling)
Auxiliary Output 1
Assignment
sub1 Alarm 1* Alarm 1* Alarm 1* Alarm 1*
Auxiliary Output 2
Assignment
sub2 Alarm 2 Control output
(cooling)
Alarm 2 Alarm 2
Auxiliary Output 3
Assignment
sub3 Alarm 3Alarm 3Alarm 3Alarm 3
Parameter name Display
Without control output 2 With control output 2
Standard Heating/cooling Standard Heating/cooling
Control Output 1
Assignment
out1 Control output
(heating)
Control output
(heating)
Control output
(heating)
Control output
(heating)
Control Output 2
Assignment
out2 --- --- Not assigned. Control output
(cooling)
Auxiliary Output 1
Assignment
sub1 Alarm 1* Alarm 1* Alarm 1* Alarm 1*
Auxiliary Output 2
Assignment
sub2 Alarm 2Alarm 2Alarm 2Alarm 2
Auxiliary Output 3
Assignment
sub3 Alarm 3Alarm 3Alarm 3Alarm 3
Auxiliary Output 4
Assignment
sub4 Alarm 4 Control output
(cooling)
Alarm 4 Alarm 4
