E5@C-T Digital Temperature Controllers User’s Manual (H185)
Conventions Used in This Manual
“E5@C-T” is used to indicate information that is the same for the E5CC-T, E5EC-T, and E5AC-T Digital
Controllers. Also, “E5EC-TPR@,” “E5AC-TPR@,” or “Position-proportional Models” indicates the Digital
Controllers with position-proportional control. “Standard Models” indicates other Digital Controllers.
The following abbreviations are used in parameter names, figures, and other descriptions. These
abbreviations mean the following:
* “EU” stands for Engineering Unit. EU is used as the minimum unit for engineering units such as °C, m, and g.
The size of the EU depends on the input type. For example, when the input temperature setting range is −200
to 1,300°C, 1 EU is 1°C, and when the input temperature setting range is −20.0 to 500.0°C, 1 EU is 0.1°C.
For analog inputs, the size of the EU depends on the decimal point position of the scaling setting, and 1 EU is
the minimum scaling unit.
Model Notation
Meanings of Abbreviations
Symbol Term
PV Process value
SP Set point
SV Set value
AT Au to- tuni ng
EU Engineering unit*
LBA Loop burnout alarm
HB Heater burnout
HS Heater short
FSP Fixed SP
PSP Program SP
