Omron E5*C Series User Manual

6 - 105
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-10 Advanced Function Setting Level
6
pf
PF Setting
• This parameter sets the function of the PF Key.
• The default is SHFT (Digit Shift).
*1 The reset operation for a Reset or Reverse Run/Reset setting is implemented by pressing the PF
Key for at least two seconds. The Run operation is implemented by pressing the PF Key for at
least one second.
*2 When AT cancel is specified, it means that auto-tuning is cancelled regardless of the type of
auto-tuning that is currently being executed.
*3 AT-1 or ATA1 can be set for heating/cooling control or position-proportional (floating) control, but
the function is disabled.
*4 Alarms 1 to 4, the HB alarm, and the HS alarm are cancelled.
*5 For details on auto/manual operations using the PF Key, refer to 5-11 Performing Manual
Control.
* Operation will be performed according to the setting of this parameter when the PF Key is pressed
for at least one second. (This does not apply to the reset operation when Reverse Run/Reset is
set.) If Monitor/Setting Items is selected, the display will switch between monitor/setting items 1 to
5 each time the key is pressed.
* The PF Key is enabled only when the PF Key Protect parameter is set to OFF.
z Related Parameters
Monitor/Setting Item 1 to 5 (Advanced Function Setting Level): Page 6-106
Function
Setting
Set value Setting Function
OFF: off Disabled Does not operate as a function key.
RUN: run RUN Specifies RUN status.
RST: rst Reset Specifies Reset status.*1
R-R: r-r Reverse Run/Reset Specifies reversing operation status between Run and
Reset.*1
HOLD: hold Reverse Hold/Clear
Hold
Specifies reversing operation status between Hold and
Hold Clear.
ADV: adv Advance Specifies performing advance operation.
AT-2: at-2 100%AT
Execute/Cancel
Specifies reversing 100% AT Execute/Cancel status.
*2
AT-1: at-1 40%AT
Execute/Cancel
Specifies reversing 40% AT Execute/Cancel status.
*2 *3
ATA2: ata2 All PID 100% AT
Execute/Cancel
Specifies reversing 100% AT execute/cancel status for all
PID sets.
*2
ATA1: ata1 All PID 40% AT Exe-
cute/Cancel
Specifies reversing 40% AT execute/cancel status for all
PID sets.
*2 *3
LAT: lat Alarm Latch Cancel
Specifies canceling alarm latches.
*4
A-M: a-m Auto/Manual
Specifies reversing Auto/Manual status.
*5
PFDP: pfdp Monitor/Setting Item Specifies the monitor/setting item display. Select the
monitor/setting item using the Monitor/Setting Item 1 to 5
parameters (Advanced Function Setting Level).
SHIFT: shft Digit Shift Operates as a Digit Shift Key when settings are being
changed.
