2-3 Insulation Block Diagrams
2
2-3 Insulation Block Diagrams
The insulation block diagrams are provided in this section.
E5CC, E5EC, E5EC-B, or E5AC
 Models with 2 Auxiliary Outputs
 Model with 3 Auxiliary Outputs (E5CC Only)
 Models with 4 Auxiliary Outputs
Sensor input, CT inputs, potentiometer input, and remote SP input
Communications and event inputs
Voltage outputs (for driving SSR), linear current outputs, and transfer output
Relay outputs
Auxiliary output 1
Auxiliary output 2
: Reinforced insulation
: Functional isolation
Power
supply
Voltage outputs (for driving SSR), linear current outputs, and transfer output
Relay outputs
Auxiliary outputs 1, 2, and 3
Sensor input, CT inputs, and remote SP input
Communications and event inputs
: Reinforced insulation
: Functional isolation
Power
supply
Voltage outputs (for driving SSRs), linear current outputs, and transfer output
Relay outputs
Auxiliary outputs 1 and 2
Auxiliary outputs 3 and 4
Sensor input, CT inputs, potentiometer input, and remote SP input
Communications and event inputs
: Reinforced insulation
: Functional isolation
Power
supply
