6-6 PID Setting Level
6
These parameters set the PID constants for each PID set number. If auto-tuning is executed, these
parameters are set automatically.
These parameters set the output dead band width for heating/cooling control for each PID set number.
A negative setting sets an overlapping band.
*.c-p
PID * Proportional Band (Cooling)
The control must be set to heating/cooling control
and 2-PID control.
*.c-i
PID * Integral Time (Cooling)
*.c-d
PID * Derivative Time (Cooling)
(*: 1 to 8)
These parameters set the PID constants for cooling control.
These parameters are automatically set according to the Heating/Cooling Tuning Method
parameter when auto-tuning is executed.
* The unit is determined by the setting of the Integral/Derivative Time Unit parameter.
The Proportional Band (Cooling), Integral Time (Cooling), and Derivative Time (Cooling)
parameters are initialized if the Integral/Derivative Time Unit parameter is changed.
z Related Parameters
AT Execute/Cancel (Adjustment Level): Page 6-27
Integral/Derivative Time Unit (Advanced Function Setting Level): Page 6-86
*.cdb
PID * Dead Band (*: 1 to 8)
The control method must be set to heating/cooling
control.
• These parameters set an area in which the control output is 0 centering around the set
point for a heating/cooling control.
Function
Setting
Parameter Setting range Unit Default
Proportional Band
(Cooling)
Temperature input 0.1 to 999.9 °C or °F8.0
Analog input %FS 10.0
Integral Time
(Cooling)*
Integral/Derivative
Time Unit of 1 s
0 to 9,999 Seconds 233
Integral/Derivative
Time Unit of 0.1 s
0.0 to 999.9 Seconds 233.0
Derivative Time
(Cooling)*
Integral/Derivative
Time Unit of 1 s
0 to 9,999 Seconds 40
Integral/Derivative
Time Unit of 0.1 s
0.0 to 999.9 Seconds 40.0
See
See
Function
Setting
Setting range Unit Default
Temperature input −199.9 to 999.9 °C or °F0.0
Analog input −19.99 to 99.99 %FS 0.00
