Omron E5*C Series

4 - 11
4 Basic Operation
E5@C Digital Temperature Controllers User’s Manual (H174)
4-3 Setting the Input Type
4
4-3-1 Input Type
4-3 Setting the Input Type
The Digital Controller supports four input types: resistance thermometer, thermocouple, infrared tem-
perature sensor, and analog inputs. Set the input type that matches the sensor that is used.
Additional Information
Changes that are made with key operations are applied when the O or M Key is pressed. They
are also applied if you do nothing for 3 seconds or longer.
4-3-1 Input Type
The following example shows how to set a K thermocouple for −20.0 to
500.0°C (input type 6).
Operating Procedure
1 Press the O Key for at least 3 seconds to move from the
Operation Level to the Initial Setting Level. The in-t (Input
Type) parameter will be displayed.
Initial Setting Level
2 Press the U or D Key to select 6 (K thermocouple at −20.0 to
500.0°C).
The default is 5 (5: K thermocouple at −200 to 1,300°C).
5
in-t
Input Type
6
in-t
