6 Parameters
6 - 12
E5@C-T Digital Temperature Controllers User’s Manual (H185)
This parameter measures the heater current from the CT input used for detecting heater burnout.
rptm
Program Execution Repetitions
Monitor
• This parameter monitors the number of times the program has been repeated.
z Related Sections
5-15 Program-related Functions (page 5-53)
z Related Parameters
Program Repetitions (Program Setting Level): Page 6-22
ct1
Heater Current 1 Value Monitor
HB and HS alarms must be supported.
The HB ON/OFF parameter must be set to ON.
This parameter measures and displays the heater current value.
• Heater burnout is not detected if the ON time for the control output for heating is 100 ms
or less (30 ms or less if the control period is 0.1 or 0.2 s).
• ffff is displayed when 55.0 A is exceeded.
• If an alarm is output for the Heater Burnout Detection 1 parameter, the No. 1 display will
flash the Heater Current 1 Value Monitor parameter.
z Related Parameters
Heater Burnout Detection 1 (Adjustment Level): Page 6-30
Heater Burnout Detection 2 (Adjustment Level): Page 6-31
HB ON/OFF (Advanced Function Setting Level): Page 6-84
Error Display ct1: Page A-13
Function
Monitor
Monitor range Unit
0 to 9,999 Repetitions
See
See
Function
Monitor
Monitor range Unit
0.0 to 55.0 A
See
See
To Next Page
