E5@C-T Digital Temperature Controllers User’s Manual (H185)
5-19 Setting the PF Key
5
5-19-1 PF Setting (Function Key)
z Monitor/Setting Item
*1 With the E5CC-T, only the PV and SP can be displayed.
Monitor/Setting Item 1
(Advanced Function Setting
Level)
Setting the PF Setting parameter to the Monitor/Setting Item makes it
possible to display monitor/setting items using the S Key. The following table
shows the details of the settings. For setting (monitor) ranges, refer to the
applicable parameter.
Set value Setting
Remarks
Monitor/Setting Display
0Disabled ---
1 PV/SP/Program No. Monitor and Segment
No. Monitor
Can be set. (SP)
*1
---
2 PV/SP/MV (Heating) (Valve Opening for
Position-proportional Models)
Can be set. (SP)
*1
---
3 PV/SP/MV (Cooling)
Can be set. (SP)
*1
---
4 PV/SP/Remaining Segment Time Can be set. ---
5 Program Number Can be set. prg
6 Segment No. Monitor Can be set. seg
7 Remaining Standby Time Monitor Can be set. stbm
8 Elapsed Program Time Monitor Can be set. prgt
9 Remaining program time monitor Can be set. prgr
10 Elapsed Segment Time Monitor Can be set. segt
11 Remaining Segment Time Monitor Can be set. segr
12 Program Execution Repetitions Monitor Can be set. rptm
13 Proportional band Can be set. *.p
14 Integral time Can be set. *.i
15 Derivative time Can be set. *.d
16 Proportional Band (Cooling) Can be set. *.c-p
17 Integral Time (Cooling) Can be set. *.c-i
18 Derivative Time (Cooling) Can be set. *.c-d
19 Alarm value 1 Can be set. al-1
20 Alarm value upper limit 1 Can be set. al1h
21 Alarm value lower limit 1 Can be set. al1l
22 Alarm value 2 Can be set. al-2
23 Alarm value upper limit 2 Can be set. al2h
24 Alarm value lower limit 2 Can be set. al2l
25 Alarm value 3 Can be set. al-3
26 Alarm value upper limit 3 Can be set. al3h
27 Alarm value lower limit 3 Can be set. al3l
28 Alarm value 4 Can be set. al-4
29 Alarm value upper limit 4 Can be set. al4h
30 Alarm value lower limit 4 Can be set. al4l
Setting Item 5
0
pfd5
1
pfd1
